Technical Specifications
Overall Length (mm): 2150 |
Overall Width Without side marker (mm): 1500- 1520 |
Overall, Height (Lowered position) (mm): 890-900 |
Machine weight (Kg): 150 (Approx) |
Engine Type: Air-cooled, 4 Cylinder, OHV, Gasoline Engine |
Engine power: 4.5 HP |
Output/Speed Kw: 3.3-3.5 kW@ 3600 rpm |
Total Displacement (cc): 170 |
Starting Method: Electrical Self Starting Method |
Fuel tank capacity (Liters): 04-05 |
Hydraulic oil tank: 0.5 - 0.6L |
Type of Wheel: Rubber/Aluminum coated steel |
Tire Diameter (mm): 650-660 |
Tire Height adjustment: Automatic, Hydraulic |
Transplanting speed m/sec: 0.30 to 0.75 |
Traveling Speed Forward m/sec: 0.70 to 1.50 |
Traveling Speed Reverse m/sec: 0.20 to 0.40 |
Number of transplanting rows at once: 4 |
Transplanting width Row to Row (mm): 300-350 |
Transplanting depth adjustments: 6 Positions |
Lifting up system: Hydraulic |
Transplanting depth control: Hydraulic |
Transplanting Vertical Space adjustment: 10 positions |
